CV-15HR 1/4" PT Female Thread Vacuum Generator Pneumatic Ejector Fitting - High Efficiency Air Suction for Industrial Automation & Packaging Machinery

Product Name Vacuum Ejector Model CV-15HR Nozzle Diameter 1.5mm Vacuum Thread Dia 11.44mm/ 1/4"PT Inlet Thread Dia 11.44mm/ 1/4"PT Outlet Thread Dia 11.44mm/ 1/4"PT Mounting Size 4.3 x 20mm/ 0.17" x 0.79" ( Hole Dia * Distance) Flow Medium Air Operating Pressure 0.1 ~ 0.6Mpa Air Comsumption 95 L/min Vacuum Degree -20-88Kpa Working Temperature 0-60oC Total Size 78 x 35 x 20mm/ 3.1" x 1.4" x 0.79" (L*W*T) Main Material Aluminum Alloy Color Silver Tone Net Weight 131g Package 1 x Vacuum Ejector Descriptions: Great replacement for the broken one. The air directlythrough theexhaustvalvequicklyexhaust,cylindertoachieverewindaction. Suitable for industrial field use.||1)
